The Electric Thermal Oil Heater is a closed-loop liquid-phase heating system designed for industrial processes requiring stable and precise temperature control. The system consists of a heating chamber, circulation pump, expansion tank, electrical control panel, and temperature sensors.
| Parameter | Value |
|---|---|
| Heating Power | 10 – 4000 kW (customizable) |
| Thermal efficiency | >98% |
| Temperature Range | Up to 350°C |
| Control Accuracy | ±1°C |
| Power Supply | 220V / 380V / 660V, 50/60Hz |
| Explosion-Proof Rating | Optional (BT4/6 CT4/6) |
The standard model offers reliable performance for general industrial heating applications. For hazardous environments, an explosion-proof version is also available.
| Power (kW) | Oil pump (kW) | Elevated tank | System oil level (L) |
|---|---|---|---|
| 10 | 1.5 | Φ 325 X 500 | 15 |
| 60 | 5.5 | Φ 400 X 700 | 52 |
| 120 | 7.5 | Φ 500 X 900 | 105 |
| 180 | 11 | Φ 600 X 900 | 230 |
| 200 | 11 | Φ 700 X 1200 | 260 |
| 240 | 11 | Φ 700 X 1200 | 285 |
| 300 | 15 | Φ 700 X 1200 | 358 |
| ... | ... | ... | .. |
| 4000 | 55 | Φ 2000 X 300 | 3300 |
A1: The system is designed to provide stable heating up to a maximum temperature of 350°C, with a high control accuracy of ±1°C.
A2: The standard model offers a heating power range from 10 kW up to 4000 kW. Custom capacities can also be built based on your specific requirements.
A3: Yes, the heater features multiple integrated safety systems including an over-temperature alarm, over-pressure protection, and a low flow cut-off to ensure safe daily operations.
A4: Yes, an optional explosion-proof version with a rating of BT4/6 or CT4/6 is available for facilities operating in hazardous environments.
A5: This electric thermal oil heater is highly efficient, delivering a thermal efficiency of greater than 98% during liquid-phase heating.
A6: It is widely used for reactor heating in chemical and pharmaceutical processes, press and dryer heating in plastics and rubber, food processing and packaging lines, and industrial oven or drum heating.
